Description
| Frame | Ultralight 500 Series OCLV Carbon, Ride Tuned performance tube optimization, tapered head tube, internal routing, DuoTrap S compatible, flat mount disc, 142x12mm thru axle |
|---|---|
| Fork | Émonda SL full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm thru axle |
| Frame fit | H1.5 Race |
Wheels
| Wheel front | Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35mm rim depth, 100x12mm thru axle |
|---|---|
| Wheel rear | Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 35mm rim depth, Shimano 11/12-speed freehub, 142x12mm thru axle |
| Skewer front | Bontrager Switch thru axle, removable lever |
| Skewer rear | Bontrager Switch thru axle, removable lever |
| Tire | Bontrager R2 Hard-Case Lite, aramid bead, 60 tpi, 700x25c |
| Max tire size | 28c |
Drivetrain
| Shifter | Shimano 105 R7170 Di2, 12 speed |
|---|---|
| Front derailleur | Shimano 105 R7150 Di2, braze-on, down swing |
| Rear derailleur | Shimano R7150 Di2, 36T max cog |
| *Crank | Size: 47 Shimano 105 R7100, 50/34, 165mm length |
| Size: 50, 52 Shimano 105 R7100, 50/34, 170mm length |
|
| Size: 54, 56, 58 Shimano 105 R7100, 50/34, 172.5mm length |
|
| Size: 60, 62 Shimano 105 R7100, 50/34, 175mm length |
|
| Bottom bracket | Praxis, T47 threaded, internal bearing |
| Cassette | Shimano 105 7100, 11-34, 12 speed |
| Chain | Shimano SLX M7100, 12 speed |
| Max chainring size | 1x: 50T, 2x: 53/39 |
Components
| Saddle | Bontrager Aeolus Comp, steel rails, 145mm width |
|---|---|
| *Seatpost | Size: 47, 50, 52, 54 Bontrager carbon seatmast cap, 20mm offset, short length |
| Size: 56, 58, 60, 62 Bontrager carbon seatmast cap, 20mm offset, tall length |
|
| *Handlebar | Size: 47, 50 Bontrager Elite Bontrager Elite VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 38cm width |
| Size: 52 Bontrager Elite Bontrager Elite VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 40cm width |
|
| Size: 54, 56, 58 Bontrager Elite Bontrager Elite VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 42cm width |
|
| Size: 60, 62 Bontrager Elite Bontrager Elite VR-C, alloy, 31.8mm, 100mm reach, 124mm drop, 44cm width |
|
| Handlebar tape | Bontrager Supertack Perf tape |
| *Stem | Size: 47 Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 70mm length |
| Size: 50 Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 80mm length |
|
| Size: 52, 54 Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 90mm length |
|
| Size: 56 Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 100mm length |
|
| Size: 58, 60, 62 Bontrager Pro, 31.8mm, Blendr compatible, 7 degree, 110mm length |
|
| Brake rotor | Shimano RT70, centerlock, 160mm |
| Rotor size | Max brake rotor sizes: 160mm front & rear |
Accessories
| Battery | Shimano BT-DN300 |
|---|---|
| Charger | Charging cable included |
Weight
| Weight | 56 – 8.25 kg / 18.19 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 275 pounds (125 kg). |
