Description
- Frame with Fork
- 900 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic-only routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142×12 mm thru axle
- Fork
- Madone Gen 8 one-piece carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12×100 mm chamfered thru axle
- Weight
- ML – 6.90 kg / 15.22 lbs (with tubes, no bottles/cages)
- Weight limit
- This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 125 kg (275 lb).
- Battery
- SRAM AXS battery pack (with charger)
- Shifter
- SRAM RED AXS E1
- Front derailleur
- SRAM RED AXS E1, braze-on
- Rear derailleur
- SRAM RED AXS E1, 36T max cog
- *Crank
- Size: XS, S
SRAM RED AXS E1, power meter, 48/35, DUB, 160 mm length Size: M, ML
SRAM RED AXS E1, power meter, 48/35, DUB, 165 mm length Size: L, XL
SRAM RED AXS E1, power meter, 48/35, DUB, 170 mm length - Bottom bracket
- SRAM DUB, T47 threaded, internal bearing
- Cassette
- SRAM RED XG-1290 E1, 10-33, 12-speed
- Chain
- thSRAM RED E1
- Max. chainring size
- 1x: 54T, 2x: 56/43
- Wheel front
- The Bontrager Aeolus RSL 65X, OCLV Carbon, Tubeless Ready, 100×12 mm thru-axle, 50th anniversary edition
- Wheel rear
- Bontrager Aeolus RSL 65X, OCLV Carbon, Tubeless Ready, SRAM XDR freehub, 142×12 mm thru-axle, 50th anniversary edition
- Skewer front
- Bontrager Switch chamfered thru axle
- Skewer rear
- Bontrager Switch chamfered thru axle, removable lever
- Tyre
- Pirelli P Zero Race TLR RS, 120 tpi, tubeless-compatible, 700×28 mm
- Max tyre size
- 32mm (as measured, see manual for details)
- Saddle
- Aeolus RSL, carbon rails, 145 mm width, 50th anniversary edition
- Seatpost
- Madone aero carbon seat post, 0 mm offset, short length
- *Handlebar/stem (integrated)
- Size: XS
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 35 cm control width, 38 cm drop width, 80 mm stem length Size: S
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 37 cm control width, 40 cm drop width, 90 mm stem length Size: M
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 90 mm stem length Size: ML, L
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 39 cm control width, 42 cm drop width, 100 mm stem length Size: XL
Trek Aero RSL Road integrated bar/stem, OCLV Carbon, Race Fit, 80 mm reach, 124 mm drop, 41 cm control width, 44 cm drop width, 110 mm stem length - Handlebar tape
- Trek EcoTack, 50th anniversary edition
- Brake rotor
- SRAM Paceline X, rounded, CentreLock, 160 mm
- Rotor size
- Max brake rotor sizes: 180 mm front, 160 mm rear
