Description
車架：Alpha Gold Aluminium，兼容 DuoTrap S，內部走線，平面安裝盤，機架和擋泥板安裝座，135x5mm 快拆
|
| Size | Rider Height | Inseam |
|---|---|---|
| XS |
147 – 155 cm 4’10” – 5’1″ |
69 – 73 cm 27″ – 29″ |
| S |
155 – 165 cm 5’1″ – 5’5″ |
72 – 78 cm 28″ – 31″ |
| M |
165 – 175 cm 5’5″ – 5’9″ |
77 – 83 cm 30″ – 33″ |
| L |
175 – 186 cm 5’9″ – 6’1″ |
82 – 88 cm 32″ – 35″ |
| XL |
186 – 197 cm 6’1″ – 6’6″ |
87 – 93 cm 34″ – 37″ |
| 2XL |
197 – 203 cm 6’6″ – 6’8″ |
92 – 95 cm 36″ – 37″ |
Frameset
| Frame | Alpha Gold Aluminum, DuoTrap S compatible, internal cable routing, flat mount disc, rack & fender mounts, 135x5mm QR |
|---|---|
| Fork | FX Steel, flat mount disc, rack mounts, 405mm axle-to-crown, ThruSkew 5mm QR |
Wheels
| Hub front | Formula DC-20, alloy, 6-bolt, 5x100mm QR |
|---|---|
| Hub rear | Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5mm QR |
| Rim | Bontrager Connection, alloy, double-wall, 32-hole, schrader valve |
| Tire | Bontrager H2 Comp, wire bead, 30tpi, 700x35c |
| Max tire size | 38c without fenders, 35c with fenders |
Drivetrain
| Shifter | Shimano EF500, 8 speed |
|---|---|
| Front derailleur | Shimano Tourney TY710, 34.9mm clamp, top swing, dual pull |
| Rear derailleur | Shimano Altus M310 |
| Crank | Forged alloy, 46/30, chainguard, 170mm length |
| Bottom bracket | Sealed cartridge, 68mm |
| Cassette | Shimano HG31, 11-32, 8 speed |
| Chain | KMC Z8.3 |
| Pedal | Wellgo nylon platform |
| Max chainring size | 1x: 42T, 2x/3x: 48T |
Components
| Saddle | Bontrager Sport |
|---|---|
| Seatpost | Bontrager alloy, 27.2mm, 12mm offset, 330mm length |
| *Handlebar | Size: XS, S, M, L Bontrager Riser, steel, 25.4mm, 30mm rise, 600mm width |
| Size: XL, XXL Bontrager Riser, steel, 25.4mm, 30mm rise, 620mm width |
|
| Grips | Bontrager Satellite |
| *Stem | Size: XS, S, M Bontrager alloy, 25.4mm clamp, 10 degree, 90mm length |
| Size: L, XL, XXL Bontrager alloy, 25.4mm clamp, 10 degree, 110mm length |
|
| Headset | 1 1/8” steel threadless |
| Brake | Tektro MD-U310 mechanical disc, flat mount, 160mm rotor |
| Rotor size | Max brake rotor size: 160mm |
Weight
| Weight | M – 12.68 kg / 27.96 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg). |
