Description
| Frame | 400 series OCLV Carbon, internal routing, 3s chain keeper, DuoTrap S compatible, mudguard mounts, flat mount disc, 135×5 mm ThruSkew |
|---|---|
| Fork | Carbon, hidden mudguard mounts, flat mount disc, 100×5 mm thru-skew |
Weight
| Weight | M – 9.50 kg / 20.95 lbs |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
E-system
| Battery | SRAM eTap battery pack (with charger) |
|---|
Drivetrain
| Rear derailleur | SRAM Apex XPLR eTap AXS, 44T max cog |
|---|---|
| *Crank | Size: XS, S SRAM Apex 1, 40T, DUB Wide, 170 mm length |
| Size: M, L, XL SRAM Apex 1, 40T, DUB Wide, 175 mm length |
|
| Bottom bracket | SRAM DUB, 86.5 mm, PressFit |
| Cassette | SRAM XPLR PG-1231, 11-44, 12-speed |
| Chain | SRAM Apex, 12-speed |
| Pedal | Bontrager City pedals |
| Max. chainring size | 1x: 44T |
Wheels
| Wheel front | Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, 100×5 mm QR |
|---|---|
| Wheel rear | Bontrager Aeolus Elite 35, OCLV Carbon, Tubeless Ready, Shimano 11-speed freehub, 135x5mm skewer |
| Hub front | Bontrager Affinity, Tubeless Ready, centerlock, 100x5mm axle |
| Skewer front | 135×5 mm bolt-on |
| Hub rear | Bontrager Affinity Comp, Shimano 11/12 speed freehub, 142x5mm |
| Skewer rear | 169×5 mm bolt-on |
| Tyre | Bontrager GR1 Expert, Hard-Case Lite, wire bead, 60 tpi, 700×40 mm |
| Max tyre size | 42mm without mudguards, 40mm with mudguards |
Components
| Saddle | Bontrager Montrose Comp, steel rails, 138 mm width |
|---|---|
| Seatpost | Bontrager Comp, 6061 alloy, 27.2 mm, 8 mm offset, 330 mm length |
| *Handlebar | Size: XS, S, M Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 600 mm width |
| Size: L, XL Bontrager Satellite Plus IsoZone, alloy, 31.8 mm, 15 mm rise, 660 mm width |
|
| Grips | Bontrager Satellite IsoZone Plus, lock-on, ergonomic |
| *Stem | Size: XS Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 90 mm length |
| Size: S, M Bontrager Elite, 31.8 mm clamp, Blendr-compatible, 7-degree, 100 mm length |
|
| Size: L, XL Bontrager Elite, 31.8 mm clamp, Blendr-compatible, 7-degree, 110 mm length |
|
| Brake | Shimano hydraulic disc, MT201 lever, UR300 calliper |
| Brake rotor | Shimano RT10, CenterLock, 160 mm |
| Rotor size | Max brake rotor sizes: 160 mm front and rear |
**跟腳踏
