Description
Frameset
| Frame | SL OCLV Mountain Carbon, IsoStrut, UDH, 80 mm travel |
|---|---|
| Fork | RockShox Recon Gold RL, DebonAir spring, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, 15 mm Maxle Stealth, 100 mm travel |
| Shock | Trek IsoStrut, RockShox SIDLuxe, 2-position remote damper |
| Max compatible fork travel | 120 mm (533 mm axle-to-crown) |
Wheels
| Wheel front | Bontrager Kovee Comp 23, Tubeless Ready, 6-bolt, Boost110, 15 mm thru axle |
|---|---|
| Wheel rear | Bontrager Kovee Comp 23, Tubeless Ready, Shimano Microspline freehub, Rapid Drive 108, Boost148 |
| Tyre part | Bontrager TLR sealant, 180 ml/6 oz |
| Rim strip | Bontrager TLR |
| Max tyre size | Frame: 29×2.40″, Fork: See manufacturer |
Drivetrain
| Shifter | Shimano Deore M6100, 12-speed |
|---|---|
| Rear derailleur | Shimano SLX M7100, long cage |
| *Crank | Size: S, M Shimano MT512, 32T, 55 mm chain line, 170 mm |
| Size: M/L, L, XL Shimano MT512, 32T, 55 mm chain line, 175 mm |
|
| Bottom bracket | Shimano MT500, 92 mm, PressFit |
| Cassette | Shimano Deore M6100, 10-51, 12-speed |
| Chain | Shimano Deore M6100, 12-speed |
| Max. chainring size | 1x: 38T, min 30T |
Components
| Saddle | Bontrager Verse Comp, steel rails, 145 mm width |
|---|---|
| *Seatpost | Size: S Bontrager Line Dropper, 100mm travel, MaxFlow, internal routing, 31.6 mm, 310 mm length |
| Size: M, M/L Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 31.6 mm, 410 mm length |
|
| Size: L, XL Bontrager Line Dropper, 170 mm travel, MaxFlow, internal routing, 31.6 mm, 450 mm length |
|
| *Handlebar | Size: S Bontrager Comp, alloy, 31.8 mm, 5 mm rise, 720 mm width |
| Size: M, M/L, L, XL Bontrager Rhythm Comp, alloy, 31.8 mm, 15 mm rise, 750mm width |
|
| Grips | Bontrager XR Trail Comp, nylon lock-on |
| *Stem | Size: S Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 50 mm length |
| Size: M, M/L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 60 mm length |
|
| Size: L Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length |
|
| Size: XL Bontrager Elite, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length |
|
| Head set | FSA IS-2, 1-1/8″ top, 1.5″ bottom |
| Brake | Shimano hydraulic disc, MT501 lever, MT500 caliper |
| *Brake rotor | Size: S, M, M/L, L, XL Shimano RT54, CentreLock, 160 mm |
| Size: S, M, M/L, L, XL Shimano RT54, CentreLock, 180 mm |
|
| Rotor size | Max brake rotor sizes: 160 mm front and rear |
Weight
| Weight | M – 13.10 kg/28.89 lb (with TLR sealant, no tubes) |
|---|---|
| Weight limit | This bike has a maximum total weight limit (combined weight of bicycle, rider and cargo) of 136 kg (300 lb). |
